Figure 5-4: 4–20 mA and pulse wiring with electronic totalizer/counter
+
-
R
L
≥250 Ω
+
-
100 Ω ≤ R
L
≤ 100 kΩ
A
B
A. Power supply
B. Power supply with counter
Quick Start Guide October 2018
18 Rosemount
™
8800D Series Vortex Flowmeter
