Safety messages
NOTICE
This guide provides basic guidelines for Rosemount
™
3051S MultiVariable
™
Transmitter (3051SMV). It
also provides the basic Rosemount 3051SMV configuration guidelines for the Rosemount 3051SFA,
Rosemount 3051SFC, and Rosemount 3051SFP. It does not provide instructions for diagnostics,
maintenance, service, or troubleshooting. Refer to the Rosemount 3051SMV Reference Manual for
more instruction.This document is also available electronically on Emerson.com/Rosemount.
WARNING
Explosions could result in death or serious injury.
Installation of device in an explosive environment must be in accordance with appropriate local,
national, and international standards, codes, and practices.
Review Rosemount 3051SMV Reference Manual for any restrictions associated with a safe installation.
• Before connecting a handheld communicator in an explosive atmosphere, make sure the
instruments in the loop are installed in accordance with intrinsically safe or non-incendive field
wiring practices.
• In an explosion-proof/flameproof installation, do not remove the transmitter covers when power
is applied to the unit.
Process leaks could result in death or serious injury.
• Install and tighten process connectors before applying pressure.
Electrical shock could cause death or serious injury.
• Avoid contact with the leads and terminals. High voltage that may be present on leads can cause
electrical shock.
Conduit/cable entries
• Unless marked, the conduit/cable entries in the transmitter housing use a ½–14 NPT thread form.
Entries marked “M20” are M20 × 1.5 thread form. On devices with multiple conduit entries, all
entries will have the same thread form. Only use plugs, adapters, glands, or conduit with a
compatible thread form when closing these entries.
• When installing in a hazardous location, use only appropriately listed or Ex certified plugs, glands,
or adapters in cable/conduit entries.
Contents
Mount the transmitter .................................. 3
Consider housing rotation ............................ 9
Set the switches ......................................... 10
Connect wiring and power up ..................... 11
Engineering Assistant installation ............... 15
Flow configuration ..................................... 17
Verifying device configuration .................... 26
Trimming the transmitter ........................... 30
Safety instrumented systems installation ... 31
Product certifications ................................. 32
