Page #29 background imageLoading...
Page #29 background image
Table 7-2: Fast Keys for Direct Process Variable Output (continued)
Function Fast Key
sequence
LCD Configuration 1, 3, 8
Loop Test 1, 2, 2
Module Temperature Reading and Status 1, 4, 2, 1, 5
Module Temperature Units 1, 3, 3, 5
Poll Address 1, 4, 3, 3, 1
Process Temperature Reading and Status 1, 4, 2, 1, 4
Process Temperature Sensor Trim Options 1, 2, 4, 5
Process Temperature Unit 1, 3, 3, 4
Ranging the Analog Output 1, 2, 4, 1
Recall Factory Trim Settings 1, 2, 4, 2, 3
Sensor Information 1, 4, 4, 2
Static Pressure Sensor Lower Trim (AP Sensor) 1, 2, 4, 4, 2
Static Pressure Sensor Trim Options 1, 2, 4, 4
Static Pressure Sensor Zero Trim (GP Sensor) 1, 2, 4, 4,1
Status 1, 2, 1
Tag 1, 3, 1
Transfer Function 1, 3, 6
Variable Mapping 1, 4, 3, 4
Write Protect 1, 3, 5, 4
October 2018 Quick Start Guide
Quick Start Guide 29

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Emerson Rosemount MultiVariable 3051S Series and is the answer not in the manual?

Emerson Rosemount MultiVariable 3051S Series Specifications

General IconGeneral
TypeMultiVariable Transmitter
Accuracy±0.04% of span
Ambient Temperature Limit-40 to 185 °F (-40 to 85 °C)
ApprovalsFM, CSA, ATEX, IECEx
ServiceLiquid, Gas, Steam
Warranty5 years
Process Temperature Range-40 to 257°F (-40 to 125°C)
Response Time100 ms
Power Supply10.5 to 42 V DC
Communication ProtocolsHART, FOUNDATION Fieldbus, PROFIBUS
Housing MaterialAluminum
DisplayOptional LCD
Process Connection1/4" NPT
Electrical Connection1/2–14 NPT, M20 x 1.5
Enclosure RatingNEMA 4X, IP66
Measurement TypesDifferential Pressure, Static Pressure, Temperature
