ER5000 Series —
16
Features and Specications
3.90
[99.0]
.98
[24.9]
.54
[13.77]
.54
[13.77]
.63
[16.0]
.93
[23.7]
.75
[19.0]
.20
[5.1]
.75
[19.0]
4x
.93
[23.7]
.87
[22.1]
Gauge Port
1/8–27 NPTF
Inlet Port
1/8–27 NPTF
1/2-14 NPTF
Conduit
Connection for
USB Wiring
1/2-14 NPTF
Conduit
Connection for
Internal Wiring
Atmospheric
Reference for
Internal Sensor
Exhaust Port
1/8–27 NPTF
Mounting
Holes
#10-32 UNF
.50 FULL THREAD
[M5 X 0.8
12.7 FULL THREAD]
(4 Places)
Not Used
Not Used
ER5000
Dimensions – Side Views
All dimensions are called out in
inches [millimeters]
Contact the factory for dimensions and specications
of models ER5020, ER5040, ER5100 and ER5110.
Refer to the ER5000 Series Part Numbering System.
