Emerson Tescom ER5050 User Manual

ER5000 —
223
Internal Variables
Variable Index and Name Access Type Range:Decimal Range:Hex
46 - ID_SOLENOID_DIRECTION RW Signed 0 : 1 0 : 1
47 - ID_MIN_INLET RW Unsigned 0 : 250 0 : fa
48 - ID_MIN_EXHAUST RW Unsigned 0 : 250 0 : fa
49 - ID_OUTER_INTEGRAL_MINIMUM RW Signed -32768 : 32767 -8000 : 7fff
50 - ID_INNER_INTEGRAL_MINIMUM RW Signed -32768 : 32767 -8000 : 7fff
51 - ID_RAW_AD_SETPOINT RO Unsigned 0 : 65535 0 : ffff
52 - ID_SERIAL_NUMBER RW Unsigned 0 : 65535 0 : ffff
53 - ID_VERSION_NUMBER RW Unsigned 0 : 65535 0 : ffff
54 - ID_MIN_AD_SETPOINT RW Unsigned 0 : 4095 0 : 0fff
55 - ID_MAX_AD_SETPOINT RW Unsigned 0 : 4095 0 : 0fff
56 - ID_MIN_COMPENSATED_INTERNAL_SENSOR RW Unsigned 0 : 4095 0 : 0fff
57 - ID_MAX_COMPENSATED_INTERNAL_SENSOR RW Unsigned 0 : 4095 0 : 0fff
58 - ID_MIN_COMPENSATED_EXTERNAL_SENSOR RW Unsigned 0 : 4095 0 : 0fff
59 - ID_MAX_COMPENSATED_EXTERNAL_SENSOR RW Unsigned 0 : 4095 0 : 0fff
60 - ID_MIN_INNER_ACTUAL_ERROR RW Signed -32768 : 32767 -8000 : 7fff
61 - ID_MAX_INNER_ACTUAL_ERROR RW Signed -32768 : 32767 -8000 : 7fff
62 - ID_MIN_OUTER_ACTUAL_ERROR RW Signed -32768 : 32767 -8000 : 7fff
63 - ID_MAX_OUTER_ACTUAL_ERROR RW Signed -32768 : 32767 -8000 : 7fff
64 - ID_PWM_ CONTROL_LIMIT_STATE RW Signed 0 : 3 0 : 3
65 - ID_PWM_VALUE RO Signed -250 : 250 -fa : fa
66 - ID_INNER_INTEGRAL_DEADBAND RW Unsigned 0 : 4095 0 : 0fff
67 - ID_OUTER_INTEGRAL_DEADBAND RW Unsigned 0 : 4095 0 : 0fff
68 - ID_FEEDBACK_FILTER RW Unsigned 0 : 1 0 : 1
69 - ID_PROFILE_TYPE RO Unsigned 0 : 11 0 : b
Variable Index and Name Access Type Range:Decimal Range:Hex
70 - ID_PROFILE_STATE RW Unsigned 0 : 2 0 : 2
71 - ID_PROFILE_STEP RO Unsigned 0 : 31 0 : 1f
72 - ID_ESTOP_FLAG RW Unsigned 0 : 1 0 : 1
73 - ID_PULSE RW Unsigned 1798 : 2298 0706 : 08fa
74 - ID_EXTRA_AD1 RO Unsigned 0 : 65535 0 : ffff
75 - ID_EXTRA_AD2 RO Unsigned 0 : 65535 0 : ffff
76 - RESERVED --- --- --- ---
77 - ID_COMPENSATED_EXTRA_AD1 RO Unsigned 0 : 65535 0 : ffff
78 - ID_COMPENSATED_EXTRA_AD2 RO Unsigned 0 : 65535 0 : ffff
79 - ID_RANGE_MIN_INLET RW Unsigned 0 : 20 0 : 14
80 - ID_RANGE_MIN_EXHAUST RW Unsigned 0 : 20 0 : 14
81 - ID_PULSE_PERIOD RW Unsigned 0 : 200 0 : c8
82 - ID_PULSE_WIDTH RW Unsigned 0 : 250 0 : fa
83 - ID_PULSE_DEADBAND RW Unsigned 0 : 330 0 : 14a
84 - ID_PULSE_ENABLE RW Unsigned 0 : 1 0 : 1
85 - ID_AD_EXTRA1_TOGGLE RW Unsigned 0 : 4095 0 : 0fff
86 - ID_AD_EXTRA2_TOGGLE RW Unsigned 0 : 4095 0 : 0fff
87 - ID_EXT_FEEDBACK_SOURCE RW Unsigned 0 : 1 0 : 1
88 - ID_DIGITAL_OUTPUT1 RW Unsigned 0 : 1 0 : 1
89 - ID_DIGITAL_OUTPUT2 RW Unsigned 0 : 1 0 : 1
90 - ID_DIGITAL_OUT1_INIT RW Unsigned 0 : 1 0 : 1
91 - ID_DIGITAL_OUT2_INIT RW Unsigned 0 : 1 0 : 1
92 - ID_DA_ANALOG_OUT RW Unsigned 0 : 4095 0 : 0fff
93 - ID_TTL_ERR0 RW Unsigned 0 : 4095 0 : 0fff
