ER5000 —
74
Getting Started
Connect pressure to the system (cont.)
c. Leave the Gauge Port plugged to prevent leakage or
attach a pressure gauge, as shown in Figure 16 on the
previous page.
NOTENOTE
CAUTIONCAUTION
WARNINGWARNING
For side-mounted applications, the Gauge Port
can be used as the outlet. Plug the Outlet Port at the
bottom of the controller for these applications.
