30 Electronic Bypass Controller Installation and Commissioning Guide
Section 5 - Programming
5.1 Required Programming
The following parameters must be set to the values shown in order to ensure proper
operation of the electronic bypass package. The Menu “0” Equivalent parameters
apply to the H300 only. These settings are pre-programmed from the factory.
DO NOT change any of these values unless directed to by Emerson
technical support. Note these parameters should be programmed in the
sequence shown.
Parameter
Menu 0
Equivalent Description For H300
Setting
UnitsFan Pump
01.014
Reference selector
A1.A2 A1.A2 -
01.051
Power-up keypad reference
LASt (1) LASt (1) -
01.052
Enable hand/off/auto keypad
mode
1 1
02.006
S ramp enable
On (1) On (1) -
02.007
Maximum Rate of Change of
Acceleration
60 10 s/Max. Hz
06.012
Enable stop key
On On -
07.010 00.026
Analog input 1 destination
0 0 menu.param
07.014 00.028
Analog input 2 destination
01.036 01.036 menu.param
08.022
Digital I/O 2 source/destination
10.033 10.033 menu.param
08.023
Digital I/O 3 source/destination
06.030 06.030 menu.param
08.024
Digital I 4 destination
01.054 01.054 menu.param
08.025
Digital I 5 destination
01.041 01.041 menu.param
09.004
Logic function 1 source 1
08.003 08.003 menu.param
09.006
Logic function 1 source 2
08.006 08.006 menu.param
09.010
Logic function 1 destination
01.043 01.043 menu.param
