Emerson VERTIV Liebert Prop Fan PFH096A- L - System Weights; Figure 9 Water;Glycol-Cooled Systems, 1 and 1.5 Tons; Figure 10 Split System, Air-Cooled Systems; Table 4 Unit Weights

Site Preparation and Installation
17 Liebert
®
Mini-Mate2
™
Figure 9 Water/glycol-cooled systems, 1 and 1.5 tons
Figure 10 Split system, air-cooled systems
5.2 System Weights
Table 4 Unit weights
Model # Weights, lb (kg)
MMD12A 265 (120)
MMD12E 220 (100)
MMD14W 260 (118)
MMD18A 295 (134)
MMD18E 225 (102)
MMD20W 300 (136)
MMD22C 220 (100)
MMD23C 220 (100)
MM2CF 63 (29)
*Add 40 lb. (20 kg.) to units with free-cooling or hot water reheat coils.
Weights assume reheat and humidifier package is included.
Glycol-Cooled
System, Ducted
Glycol-Cooled
System, Grille
Water-Cooled
System, Ducted
Water-Cooled
System, Grille
Split System, Ducted
Split System, Grille
