Bareshaft Compressor Center of Gravity (Models 2401-3001)
Figure 3-5. Bareshaft Compressor Assembly Center of Gravity (Models 2401-3001)
Center of
Gravity
Main Lift
Point
Lifting Eyes
Figure 3-6. Bareshaft Compressor Center of Gravity - Discharge Manifold and Main
Compressor Assembly (Models 2401-3001)
Discharge
Manifold
Main Compressor
Assembly
Center of
Gravity
Main Lift
Point
Lifting Eyes
