6.1 CONNECTIVITY WITH CROSS CABLE
Local access from the PC is the fastest way to manage setup. It is possible to connect a PC to XWEB-EVO
through the network interface supplied with an ‘RJ45 Ethernet connector’. The connection between the two
must be set up using a cross network cable (aka 'cross cable'). This cable is available at any computer store.
Once the physical connection has been set up,
launch the browser on your PC and enter the
following in the address bar http://192.168.0.150
(XWEB-EVO default address). The connection
procedure is complete when the login page opens
up. Enter user name and password to start using
your XWEB-EVO.
.
Caution: a pre-requisite to setting the connection
up correctly is that the XWEB-EVO address and
network interface address on your PC need to
have a compatible IP class. For example, with an
XWEB-EVO network interface configured with
192.168.0.200, the network interface on your PC
can be configured with 192.168.0.15
