Eminent EM4700 - Bottom Label

6
|
ENGLISH
Bottom label
Rear, Right Panel and bottom Side decription
Label Function
ANTENNA (Optional) 2 fixed ANTENNA
ON/OFF SWITCH Power on/off the device
POWER Connects to the supplied power adaptor
LAN 4/3/2/1 Connects the device via LAN Ethernet to up to 4 PCs
WAN Connects the device via WAN Ethernet to xDSL / Cable Modem
WPS
Press this button for at least 3 full seconds and the WPS LED will
flash to start WPS.
Now go to the wireless adapter or device and press its WPS button.
Make sure to press the button within 120 seconds (2 minutes) after
pressing the router's WPS button.
RESET Reset button. RESET the 802.11ac WLAN Router to its default settings.
Press this button for at least 6 full seconds to RESET device to its default
settings.
