EMTEST N Series - Cnv 504 N1.6; Cnv 504 N2; Cnv 508 N2

EM TEST CNV 504N1/N2 / 508N1/N2
Operating manual V 1.20 14 / 23
4.3.
CNV 504N1.6
Test level
CNV 504N1.6
Rated voltage
max. 250V via 0.5 and 3.3F
50V dc with Gas arrestor
Rated current
4A
Max. test voltage (surge)
4000V 1,2/50s
Decoupling
L = 20mH
Residual voltage (decoupled side)
see calibration report
Varistor S20K 300
Coupling mode
Capacitive
Coupling C 0,5F damping resistor 40
Gas arrestor
Gas arrestor alternative selectable to coupling C 0,5F
Ringwave
coupling C 3.3F
Output
Number data lines
4 banana plugs
General
Dimension L x W x H
250mm x 160mm x 130mm
Weight
Approx. 9 kg
Temperature
5 - 40 C operation
Humidity
10%...90% non condensing
4.4.
CNV 504N2 / CNV 508N2
Test level
CNV 504N2 CNV 504N2.2
CNV 508N2
Rated voltage
max 50V 250V
max 50V
Rated current
1A 1A
1A
max. test voltage (surge)
7000V 1,2/50s
7000V 1,2/50s
7000V 10/700s
7000V 10/700s
Decoupling
L = 20mH
L = 20mH
Residual voltage (decoupled side)
see calibration report
max. 75V
max. 75V
Coupling mode
Capacitive
Coupling C 0,5F damping resistor 40
Gas arrestor
Gas arrestor 90V alternative selectable to coupling C 0,5F
Ringwave
coupling C 3.3F
Output
Number data lines
4 banana plugs
8 banana plugs
General
Dimension L x W x H
19",3HE 447mm x 309mm x 144mm
Weight approx.
7.45kg
approx. 8.5 kg
Temperature
5 - 40 C operation
Humidity
10%...90% non condensing
