EMTEST N Series - Technical Data; Cnv 504 N1; Cnv 508 N1; Cnv 504 N1.2, Cnv504 N1.3

EM TEST CNV 504N1/N2 / 508N1/N2
Operating manual V 1.20 13 / 23
4.
Technical data
4.1.
CNV 504N1 / CNV 508N1
Test level
CNV 504N1
CNV 508N1
Rated voltage
max 50V
Max50V
Rated current
1A
1A
Max. test voltage (surge)
4000V 1,2/50s
4000V 1,2/50s
Decoupling
L = 20mH
L = 20mH
Residual voltage (decoupled side)
see calibration report
max. 75V
max. 75V
Coupling mode
Capacitive
Coupling C 0,5F damping resistor 40
Gas arrestor
Gas arrestor 90V alternative selectable to coupling C 0,5F
Ringwave
coupling C 3.3F
Output
Number data lines
4 banana plugs
8 banana plugs
General
Dimension L x W x H
250mm x 160mm x 130mm
Weight
5.00kg
approx. 6.5 kg
Temperature
5 - 40 C operation
Humidity
10%...90% non condensing
4.2.
CNV 504N1.2, CNV504N1.3
Test level
CNV 504N1.2
CNV 504N1.3
Rated voltage
max 250V
max 250V
Rated current
1A
4A
Max. test voltage (surge)
4000V 1,2/50s
4000V 1,2/50s
Decoupling
L = 20mH
L = 20mH
Residual voltage (decoupled side)
see calibration report
Varistor S20K 300
Varistor S20K 300
Coupling mode
Capacitive
Coupling C 0,5F damping resistor 40
Gas arrestor
No Gas arrestor mounted because rated voltage >90V
Ringwave
coupling C 3.3F
Output
Number data lines
4 banana plugs
4 banana plugs
General
Dimension L x W x H
250mm x 160mm x 130mm
Weight
4.85 kg
9.65kg
Temperature
5 - 40 C operation
Humidity
10%...90% non condensing
