EM TEST CNV 504N1/N2 / 508N1/N2
Operating manual V 1.20 5 / 23
CNV 504N2
7kV coupling/decoupling network for Surge and Ringwave
with 40ohm via 0.5uF capacitor (as per Fig. 11, IEC 61000-4-5) and arrestor (as per Fig.12);
with 3.3uF capacitor for Ringwave (as per Fig. 9, IEC 61000-4-12);
Rated line voltage/current 50V/1A
CNV 504N2.1
7kV coupling/decoupling network for Surge and Ringwave
with 40ohm via 0.5uF capacitor (as per Fig. 11, IEC 61000-4-5) and arrestor (as per Fig.12);
with 3.3uF capacitor for Ringwave (as per Fig. 9, IEC 61000-4-12);
Rated line voltage/current 50V/4A
CNV 504N2.2
7kV coupling/decoupling network for Surge and Ringwave
with 40ohm via 0.5uF capacitor (as per Fig. 11, IEC 61000-4-5) and arrestor (as per Fig.12);
with 3.3uF capacitor for Ringwave (as per Fig. 9, IEC 61000-4-12);
Rated line voltage/current 250V/1A
CNV 508N2
7kV coupling/decoupling network for Surge and Ringwave onto 8 signal/data lines
with 40ohm via 0.5uF capacitor (as per Fig. 11, IEC 61000-4-5) and arrestor (as per Fig.12);
with 3.3uF capacitor for Ringwave (as per Fig. 9, IEC 61000-4-12);
Rated line voltage/current 50V/1A
CNV 508N2.1
7kV coupling/decoupling network for Surge and Ringwave onto 8 signal/data lines
with 40ohm via 0.5uF capacitor (as per Fig. 11, IEC 61000-4-5) and arrestor (as per Fig.12);
with 3.3uF capacitor for Ringwave (as per Fig. 9, IEC 61000-4-12);
Rated line voltage/current 50V/4A
CNV 508N2.2
7kV coupling/decoupling network for Surge and Ringwave onto 8 signal/data lines
with 40ohm via 0.5uF capacitor (as per Fig. 11, IEC 61000-4-5);
with 3.3uF capacitor for Ringwave (as per Fig. 9, IEC 61000-4-12);
Rated line voltage/current 250V/1A
CNV 508N2.3
7kV coupling/decoupling network for Surge onto 8 signal/data lines;
coupling via capacitor
Rated line voltage/current 250V/4A
CNV 508N3
10kV coupling/decoupling network for Surge onto 8 signal/data lines
with 40ohm via 0.5uF capacitor (as per Fig. 11, IEC 61000-4-5) and arrestor (as per Fig.12);
Rated line voltage/current 50V/1A
CNV 508N3.2
10kV coupling/decoupling network for Surge onto 8 signal/data lines
with 40ohm via 0.5uF capacitor (as per Fig. 11, IEC 61000-4-5);
Rated line voltage/current 250V/1A
CNV 508N3.3
10kV coupling/decoupling network for Surge onto 8 signal/data lines;
coupling via capacitor
Rated line voltage/current 250V/4A
