emz smart Sol - Page 51

Page 51
1.1.4.1 Heat qty. 1
04. 07. 2015
09:23
Activation
Heat qty.
Volume ow
0 kWh
Impeller 1
1.1.4.1 Heat qty. 1
04. 07. 2015 09:23
Ret.line sens.
Supp.line sens.
Glycol type
---
---
Water
1.1.4.1 Heat qty. 1
04. 07. 2015 09:23
Glycol portion
Delay
Eff-tank-charge
Add to overall HQ
20Vol%
5s
the return line sensor and the supply line sen-
sor must be specied.
Specify the heat exchanger medium: water /
propylene glycol / ethylene glycol / Tyfocor /
as antifreeze protection.
After activation, the volume ow sensor as
well as ...
COMMISSIONING MODE
Specify the portion of antifreeze in the ex-
changer medium as well as the delay.
Activate the effective tank charge, if neces-
sary, and add the heat quantity data to the
heat quantity counter.
Return by pressing the „esc“ key.
