emz smart Sol - Commissioning Mode; Commissioning Prerequisites

Page 45
0.1 Language
04. 07. 2015 09:14
Deutsch
English
Français
Italiano
Polski
0.2 Date setting
04. 07. 2015 09:14
Date
Time
Auto. Clock Change
04.07.2015
09:14
Choose scheme
Free conguration
›0.1 Language‹ appears after
a short booting sequence.
Various languages are available
in this version of the smart Sol.
Activate the required version and
acknowledge by pressing ›Next‹.
This is an explanation in terms of an example of commissioning of the
differential temperature controller smart Sol; details vary along with
the hydraulic conguration and the software version.
Commissioning is communicated in plain text; the user must make a
selection, acknowledge and - if applicable - jump to the next menu item.
The differential temperature controller smart Sol accompanies you during the
entire conguration and interrogates everything it must know for optimum operation.
Now, the power supply of the controller must be switched on - the display screen appears.
For repeat commissioning, the tter must activate the professional mode using the ac-
cess code (365).
›0.2 Time/date‹ appears.
Press „OK“ -> the rst value is highlighted.
Turn the rotary encoder until the correct value
is displayed and acknowledge with „OK“.
Enter all values in this way.
At any place of installation where European
daylight saving time is applicable, the auto-
matic time difference is activated here.
Select „Choose system“ or „Free congura-
tion“ and acknowledge with „OK“ - further
information is provided on the next pages.
COMMISSIONING MODE
Important!
For commissioning, the controller must be assembled
correctly, all inputs and outputs must be connected
and ready for operation, the strain relief device must
be screw-fastened and the terminal cover closed!
