emz smart Sol - Page 90

Page 90
1.3.1 Thermostat R...
04. 07. 2015 10:35
T ON
T OFF
t ON 1
t OFF 1
t ON 2
40.0°C
55.0°C
00:00
00:00
00:00
1.3.1 Thermostat R...
04. 07. 2015 10:35
t OFF 2
t ON 3
t OFF 3
t ON 4
t OFF 4
00:00
00:00
00:00
00:00
00:00
1.3.7 Output para...
04. 07. 2015 10:35
Tank ch.-over v 1
Solar pump 2
Boiler
t tear-off
n tear-off
10s
100%
PROFESSIONAL MODE
Dene switch-ON/OFF temperature.
For the heating function,
T ON must be < T OFF.
For the cooling function,
T ON must be > T OFF.
Up to four time slots can be
assigned to each thermostat function.
First of all, dene the switch-ON times.
Continue to scroll.
Dene times for activation and deactivation.
Continue via the menu item
›Output parameter‹.
Here, the general settings for the
assigned outputs are dened.
Continue to scroll.
