Page 12
Getting Started
E500 & E700 FITNESS SYSTEM
FEATURES
1 ) The control panel provides a quick visual
check of the
fitness system
’s status and allows
the user to set different functions of the
fitness
system
.
2) The Aux panel allows you to control the
Hydromassage jets, interior and exterior lights.
3) The Air Valve allows you to add air to your
hydromassage jets.
4) The Water Feature Lever adjusts the amount
of water that flows from the water feature.
5) The Large Hydromassage jets provide a
unique, pulsating massage.
6) The Midsize Directional Hydromassage
jets, with eyeball nozzles, deliver a direct, more
focused massage.
7) The Midsize rotational Hydromassage jets,
provide a rotating massage.
8) The Mini Hydromassage jets feature a direct
more focused massage.
9) The Hydraulic Swim Machine uses a remote
control to adjust the speed of the current.
10) The Hydraulic Treadmill (Optional) uses
a remote control to adjust the speed of the
treadmill.
11) Pillow
12) Filter Compartment Grill
13) Swim Speaker (Optional)
14) Seating Area Speaker
(Optional)
15) Suction Screen
16) Water feature
17) Ozone Jet
18) Heater Return
19) Grab Rails
20) Points of Light
21) Exercise Anchor
22) Tether Anchor
1
2
4
5
6
10
11
12
13
3
8
17
14
ADDITIONAL FITNESS SYSTEM
FEATURES
16
19
9
18
7
15
4
16
20
21
22
19
Getting Started
Your fitness system may look different than the illustration
12
21
