Operating Instructions
MAIN CONTROL PANEL
The main control panel provides a bright, full color display, and intuitive
user experience, while its screen’s high resolution brings
fitness system
user interfaces to a new level. Loaded with a large amount of memory
and a powerful on-board processor creating seamless graphic interface
that
fitness system
users have been waiting for.
MAIN CONTROL PANEL FUNCTIONS
When the screen is off, press any button to turn the control panel screen
on and display the home screen. After 30 minutes of inactivity the screen
will shut off.
The function description of the buttons below will only work from the
Home screen. Once the main control panel is placed in a submenu the
selection lights next to the buttons will light up to indicate which buttons
may be selected for a specific screen function.
SETTINGS
One press of the (Settings button) from the home page gives you
access to a menu to manage the settings of your
fitness system
where
you will find:
• Water care
• Audio (optional)
• Maintenance
• Date and time
• Keypad Settings
• Miscellaneous
• Wi-Fi (optional)
• Electrical configuration
• About
Use the or buttons to move up and down in the list. To select an
option, press the lit button beside the desired highlighted option.
IMPORTANT: At any point you can press the (Settings button) to
return to the home screen or top left button (hydromassage jets) to
go back.
WATER CARE / HEATER SETTINGS
The Water Care section will help you set up your ideal heater settings.
Choose from Away from Home, Standard,
Energy Savings, Super Energy Savings,
and Weekender, depending on your needs.
Use (middle left) button to choose
your setting. A green check mark will
appear on the selected icon to confirm.
When in Economy mode, the heating
set point will be reduced by 11°C (20°F),
which means that the heating system will not come on during the set time
unless the temperature falls 11°C (20°F) below the fitness system's set
temperature.
Because the fitness system uses a 24 hour circulation pump the filter
cycle settings are not applicable, however, the hydromassage jet pump
will purge for 1 minute at any of the filter cycle setting start times. The
factory filter cycle settings may be deleted to stop the 1 minute purge.
WATER CARE MODES
Away from home:
In this mode the fitness system will always be in economy
mode; the set point will be reduced by 11°C (20°F).
Standard:
The fitness system will never be in economy mode.
Energy Savings:
The fitness system will be in economy mode during the peak
hours of the day and resume normal mode on the weekend.
Super Energy:
The fitness system will always be in economy mode during
peak hours, every day of the week.
Weekender:
The fitness system will be in economy mode from Monday to
Friday, and will run normally on the weekend.
Default Settings:
By selecting this setting you will be asked to confirm your
choice. Doing so will revert all Water Care Modes back to
factory settings.
MODIFYING SCHEDULES
To modify a Water Care category, use
the (middle right) lit button, to open
the selected Water Care menu. The
menu screen is divided into two
settings, Economy and Purge cycle
with Economy being first. Set or
change the Day, Start and Stop time if
desired to keep the heater off
(Economy mode). Scroll down to
set or change the Purge Time Day
and Start time keeping in mind that
this will only set a 1 minute purge
cycle (duration is not changeable).
You can add schedules by scrolling
down to Add, and selecting by
using the (middle left) lit button.
Settings
Audio
Selection
Button
Selection Lights
Selection
Button
Hydromassage Jets
All Off/Memory On
Up/
Temperature
Down/
Temperature
External
Lights
Internal Lights
Operating Instructions
