PARAL·LEL PROCESSING
FW V2.0
Global dry/wet can be accessed via ROUTING + VOLUME/drive – that combo sets
the mix between the input signal after the IN GAIN (before pre-VCA) at full CCW and
the final audio chain output before the VOLUME (before post-VCA) at full CW.
RESET
In case you have tweaked everything so hard you have distorted signal main
outputs, a soft reset adjusts all advanced / secondary parameters to their default
values, so you may start tweaking from the beginning.
Press all four buttons (16) (17) (23) (25) simultaneously and hold them for more than
3 seconds. Release them once they are all four on, and module will reset to its
default values.
After the module's reset: Delay's and Reverb's /TONE* controls are in the middle (no
tone filtering applied); Reverse reverb pre-delay set to max, Hall reverb pre-delay set
to min, MIX control set to FULL WET (100%, CW value).
