FRONT PANEL CONTROLS
1. IN 1 , IN 2 JACKS: stereo audio inputs, INPUT 1 (typically left) – is
normalled , i.e. pre-routed → to INPUT 2 (right) when no audio cable is
present on INPUT 2 . Typical input audio level: eurorack modular +/-5V with
maximum up to +/-9V when saturation starts with higher audio amplitude.
Line level audio signals also accepted just bear in mind the output will also
be similar amplitude (or you can always adjust the gain with the /GAIN* knob
(3).
2. PRE-VCA CV INPUT JACK: external 0…+5V CV input that controls
the amplitude of the incoming stereo signal. Normalled to +5V when no patch
cable is inserted.
3. TONE /gain* KNOB: multi-function knob. By default it acts as a 6db/oct
TILT EQ for low and high frequencies (CCW and CW respectively) with no
effect when the knob is at 12 o’clock. Secondary function is a gain boost for
incoming audio, activated by turning while holding the ROUTING button.
Fully CCW the signal is at its original unity level - turn CW to boost.
4. DISTORTION KNOB: manual control over the distortion level. Is
summed with an external CV applied to the DIST. CV jack (5). Secondary
hidden function (holding ROUTING while turning DISTORTION ) lowers the
BITRATE
FW V3.0
amount output of the FILTER chain: full 24 bits at CCW and
crushing to a certain moment until the audio falls down to noise. When
turning feature, it radically brings aliasing to the audio signal – use on your
own discretion creatively to add lo-fi flavor.
5. DISTORTION CV JACK: external 0…+5V control over the distortion
level (4).
6. CLIP LED: lights up when clipping occurs at the distortion stage (4).
7. FREQUENCY KNOB: manual control over the FILTER CUTOFF .
8. VCF CV INPUT JACK: -5V…+5V CV input for the FILTER CUTOFF .
The polarizer CUTOFF CV knob defines its amount, mixed with the setting of
the FREQUENCY knob (7).
9. CUTOFF CV KNOB: polarizer / attenuverter for incoming CV input
jack (8) to the FILTER CUTOFF.
10. DELAY DRY/WET CV JACK: 0…+5V external CV input for the
DRY/WET mix of the delay effect (11). Normalled to +5V when no patch cable
inserted.
