Endress+Hauser
HART Loop Converter HMX50
Calling up a Fault Message
1. Use the
▴ or ▾ buttons to select the Fault message menu.
2. If the fault message menu is activated, press the OK button once.
The Restart inhibit submenu is displayed.
3. If the fault message menu is not activated, press the OK button twice.
The Restart inhibit submenu is displayed. The Fault message menu is activated and is
marked as On.
Activating the Restart Inhibit
The restart inhibit is used to prevent momentary trip value violations from not being
noticed by operating personnel.
1. Use the
▴ or ▾ buttons to select On.
2. Confirm your selection with OK.
The relay status is retained after switching the relay.
3. If you would like to reset the relay status, press the ESC or button or restart the device.
The relay is reset. Exception: there is a fault message.
Fault indication (on) —— Restart inhibit —— On
▾▴
Off
