Liquipoint T FTW 31, FTW 32
Endress + Hauser 13
Separate instrumentation for five-rod or five-rope probes with cable monitoring
L00-FTW3xxxx-04-05-xx-en-004
*1 Printed circuit board for cable monitoring
The power supply and evaluation are provided by switching units, e.g. Nivotester FTW 325 or FTW 470 Z
Cable entry M 20x1.5
• Degree of protection: IP66
• Quantity in F24 housing: 1 (separate-instrument version)
• Quantity in F16 housing: 2 (compact-instrument version)
NPT 1/2"
• Quantity in F24 housing: 1 (separate-instrument version)
• Quantity in F16 housing: 2 (compact-instrument version)
• Conductor cross-section (including wire end sleeve): 2.5 mm
Cable specifications Use a commercially available cable (25 Ω per wire).
