Nominal diameter Pressure rating Screws Max. screw tightening torque [Nm]
[mm] [bar] [mm] PTFE PFA
40 10K 4 × M16 41 37
40 20K 4 × M16 41 37
50 10K 4 × M16 54 46
50 20K 8 × M16 27 23
65 10K 4 × M16 74 63
65 20K 8 × M16 37 31
80 10K 8 × M16 38 32
80 20K 8 × M20 57 46
100 10K 8 × M16 47 38
100 20K 8 × M20 75 58
125 10K 8 × M20 80 66
125 20K 8 × M22 121 103
150 10K 8 × M20 99 81
150 20K 12 × M22 108 72
200 10K 12 × M20 82 54
200 20K 12 × M22 121 88
250 10K 12 × M22 133 –
250 20K 12 × M24 212 –
300 10K 16 × M22 99 –
300 20K 16 × M24 183 –
Screw tightening torques for AS 2129; Table E
Nominal diameter Screws Max. screw tightening torque [Nm]
[mm] [mm] PTFE
25 4 × M12 21
50 4 × M16 42
Screw tightening torques for AS 4087; PN 16
Nominal diameter Screws Max. screw tightening torque [Nm]
[mm] [mm] PTFE
50 4 × M16 42
