Proline Promag Appendix
Endress+Hauser 41
Nominal diameter Screws Max. screw tightening torque [Nm] ([lbf · ft])
[mm] [in] [in] Hard rubber Polyurethane PTFE
2 150 84 64 × 2 931 (687) – –
2 300 90 68 × 2 ¼ 1 048 (773) – –
Screw tightening torques for AS 2129; Table E
Nominal diameter Screws Max. screw tightening torque [Nm]
[mm] [mm] Hard rubber Polyurethane PTFE
350 12 × M24 203 – –
400 12 × M24 226 – –
450 16 × M24 226 – –
500 16 × M24 271 – –
600 16 × M30 439 – –
700 20 × M30 355 – –
750 20 × M30 559 – –
800 20 × M30 631 – –
900 24 × M30 627 – –
1 000 24 × M30 634 – –
1 200 32 × M30 727 – –
Screw tightening torques for AS 4087; PN 16
Nominal diameter Screws Max. screw tightening torque [Nm]
[mm] [mm] Hard rubber Polyurethane PTFE
350 12 × M24 203 – –
375 12 × M24 137 – –
400 12 × M24 226 – –
450 12 × M24 301 – –
500 16 × M24 271 – –
600 16 × M27 393 – –
700 20 × M27 330 – –
750 20 × M30 529 – –
800 20 × M33 631 – –
900 24 × M33 627 – –
