Installation Proline Prosonic Flow 91W
6 Endress+Hauser
Horizontal
In the recommended installation range in a horizontal installation position (View B), gas and air
collections at the pipe cover and problematic deposits at the bottom of the pipe have a smaller
influence on measurement.
A0001105
Fig. 2: Orientation
A Recommended orientation with upward direction of flow
B Recommended installation range with
horizontal orientation
C Recommended installation range max. 120°
A
B
CC
