Proservo NMS80 Commissioning
Endress+Hauser 69
Each Analog I/O module of the device can be configured as 4...20mA analog output. To do so,
assign appropriate values to the following parameters:
Setup → Advanced setup → Input/output → Analog I/O
Parameter Meaning / Action
Operating mode Select 4..20mA output or HART slave +4..20mA output
1)
→ 70.
Analog input source Select which tank variable is transmitted via the analog output.
Analog input 0% value Specify which value of the tank variable corresponds to an output current of 4 mA.
Analog input 100% value Specify which value of the tank variable corresponds to an output current of 20 mA.
1) "HART slave +4..20mA output " means that the Analog I/O module serves as a HART slave which cyclically sends
up to four HART variables to a HART master. For the configuration of the HART output:
