Endress+Hauser prowirl 77 - Page 26

Name E+H
Matrix
Index Read Write * Para-
meter
Data type Size
bytes
Storage
Class
View_1 Objects of Blocks in Slot 1
PB View_1 Object 201 X M
Unsigned16,
DS-37,DS-42,
Octet String[4]
17 D
TB View_1 Object 202 X M
Unsigned16,
DS-37,DS-42
float
17 D
AI View_1 Object 203 X M
Unsigned16,
DS-37,DS-42,
DS-33
18 D
Totalizer Block (TOT)
TOT Block Object 0 X M DS-32 20 C
TOT Static Revision 1 X M Unsigned16 2 N
TOT Tag Description 2 X X M Octet String 32 S
TOT Strategy 3 X X M Unsigned16 2 S
TOT Alert Key 4 X X M Unsigned8 1 S
TOT Target Mode 5 X X M Unsigned8 1 S
TOT Mode Block 6 X M DS-37 3 N/Cst
TOT Alarm Summary 7 X M DS-42 8 D
not used 8...9
TOT Out Total. V0H2 10 X M DS-33 5 D
not used 11
TOT Units V1H1 12 X X M Unsigned16 2 S
not used 13
TOT Channel 14 X X M Unsigned16 2 S
TOT Reset Total. V4H1 15 X X M Unsigned8 1 N
TOT Operating Mode 16 X X M Unsigned8 1 S
not used 17
TOT Failsafe Mode 18 X X M Unsigned8 1 S
not used 19
TOT Polarity 20 X X M Unsigned8 1 S
not used 21
TOT Alarm Hysteresis 22 X X M float 4 S
TOT HI HI Limit 23 X X M float 4 S
TOT HI Limit 24 X X M float 4 S
TOT HI HI Alarm 25 X M DS-39 16 D
TOT HI Alarm 26 X M DS-39 16 D
not used 27...31
TOT User Unit V1H4 32 X X O float 4 S
View_1 Object of Block in Slot 2
TOT View_1 Object 33 X M
Unsigned16,
DS-37,DS-42,
DS-33
18 D
* Parameter: O = Optional
M = Mandatory
The totalizer block parameters are positioned in Slot 2, the index can be found in the
following table:
5 Communication Prowirl 77 PROFIBUS-PA
26 Endress+Hauser
