Digital field display 4 Mechanical installation
33
4 Mechanical installation
4.1 Installation conditions
4.1.1 Dimensions
ƒig. 1: Dimensions
4.2 Installation
The unit is suitable for wall mounting. A combined wall/stand
pipe mounting adaptor can be ordered as an option (see
accessories).
4.2.1 Direct wall mounting
ƒig. 2: Direct wall mounting
Follow these instructions when mounting the unit directly to a
wall:
G_09_RIA261_Z_Z_06_00_08_xx_001.eps
G_09_RIA261_Z_Z_06_00_00_xx_001.eps
