11 Technical data Digital field display
44
10.5 Spare parts
10.6 Repairs
Due to its construction, the field mounted display cannot be
repaired.
10.7 Returns
If the unit is to be returned, always add a fault description as
well as the application and return the unit in its original
packaging. If this is not possible, please pack the unit safely.
10.8 Disposal
If the unit is to be disposed of please follow the local disposal
regulations for electronic components.
11 Technical data
Part description Order number
Terminals 510 02786
Operation and system construction
Application area The unit measures an analogue signal and indicates this in the
display. The unit is installed in a 4 to 20 mA current loop circuit
and also obtains the necessary energy supply from that circuit.
Measurement
priciple
The signal connected to the analogue input is digitalised,
analysed and indicated in the display.
Measurement
system
Micro-controller controlled field mounted display with illuminated
LC display.
