Digital field display 11 Technical data
47
Mechanical construction
Dimensions H: 80 mm, W: 175 mm, D: 65 mm
Weight Approx. 800 g
Materials •Housing:
Die cast aluminium, epoxy coated with glass insert
• Wall/stand pipe bracket: Stainless steel 1.4301
• Tension strip: Stainless steel 1.4301
Ter mi na ls Plug-on screw terminals, Terminal sizing:
1.5 mm² solid core, 1.0 mm² standed with ferrule
Earth (ground)
Ter mi na ls
Earth (ground) connection on housing exterior:
Terminal range 2.5 mm²
Cable entry 2 x metric M20x1.5 cable entries
alternative: 2 x NPT 1/2" cable entries
Pressure
compensation
For ventilation and pressure comensation of the electronic
compartment a mainenance free GORE-TEX
®
membrane is built
in
Electronic
compartment
There is room for the installation of a further electronic insert e.g.
Temperature head transmitter underneath the hinged electronic
components. H: 60 mm, W: 140 mm, D: 30 mm
Display and operating level
Display 5 digit LC display, 26 mm character height, rear illuminated,
analogue value display in 10% steps. Indication of over/under
range input.
Display range -19999 to +99999
Offset -19999 to +32767
Operation 3 push button operation (-/+/E)
