32
OBIS code value Type of accounted energy Tariff
• •
R-
•
4.8.A Reactive exported Tariff 10
4.8.P Reactive exported Cumulatively by the phase wire
4.8.n Reactive exported Cumulatively by the neutral wire
4.2.1 Viewing total accumulations when the meter is powered from the network
Go to the first group of meter parameters. To do this, press
6
and hold the «FRAME» button, then, after
«GROUP 1» appears on the indicator, release the button. On the LCD screen, the first frame of the viewed «GROUP 1»
group parameters will be displayed, containing information on the amount of imported active energy, cumulatively
by all tariffs.
By briefly pressing the «FRAME» button, select the type of accounted energy:
«A+» → «A-» → «R+» → «R-»
By briefly pressing the «VIEW» button, select a tariff:
«Total » → «Tariff 1 » → «Tariff 2 » → « Tariff 10 »
6
In meter modifications with LCD backlight, when the backlight is off, the first short pressing of the «FRAME» button turns on the
backlight without changing the frame.
Table 4.2 (continued)
