E. State of Charge
The open circuit voltage of the battery can be used as a guide to the state of
charge of the battery. The graph in Figure 7 is an indicator as to the state of
the charge of a new battery.
Open Circuit Voltage v SOC
Figure 7
Page 11
June 09/06
STATE OF CHARGE AS A FUNCTION OF OPEN CIRCUIT VOLTAGE
23.5
24
24.5
25
25.5
26
26.5
0 102030405060708090100110
% STATE OF CHARGE
OPEN CIRCUIT VOLTAGE
