COMPONENT MAINTENANCE MANUAL
BA27
24-01-01
This document contains Data controlled by the U.S. Export Administration Regulations. Diversion or use contrary to U.S. law is prohibited
H Charging Instructions
Charging of the Flight Controls battery should be performed using a constant
voltage charger, capable of constantly supplying 28.5 volts with a minimum supply
current of 10 amps. Using the set-up illustrated in figure 5. (Minimum charge time 6
hours)
UNOTE:U If the battery fails the first charging test per TESTING section 4.I, during
the second charging test, charge the battery for 12-24 hours.
UNOTEU: Charging should be conducted between 20°C (68°F) and 30°C (86°F).
The battery capacity may vary if charged outside this recommended
temperature range.
Page 14
Mar 13/17
