COMPONENT MAINTENANCE MANUAL
BA27
24-01-01
This document contains Data controlled by the U.S. Export Administration Regulations. Diversion or use contrary to U.S. law is prohibited
3. UDetailed Instructions
UNOTEU: The ( ) part identification numbers herein are detailed in IPL, Fig.1
item numbers.
A. Verify both new monoblocs are properly matched pairs:
- Same manufacturer
- Same part number
- Open circuit voltage is within 1%
- Date Codes or Date of Manufacture
B. Remove cover (180) by carefully drilling out the 10 rivet fastenings (210).
C. Remove the four monobloc terminal nut covers (150).
D. Remove the binx nut (140), plain washer (130), and wire from the positive
terminal of the rear monobloc (Ref Fig. 1). The nut and washer should be
discarded.
E. Remove the binx nut (140), plain washer (130), and wire from the negative
terminal of the front monobloc (Ref Fig.1). The nut and washer should be
discarded.
F. Remove the binx nuts (140), plain washers (130) and series lamination (120)
connecting the two monoblocs. The nuts, washers and laminations should
be discarded.
G. Cut wire ties (100) from the positive and negative wires.
H. Remove the anti-vibration block (160).
I. Remove the two monoblocs (20) from the outer battery case (30).
(1) Gently prise apart the case walls in the centre and remove the
monobloc adjacent to connector block.
(2) Slide the second monobloc to the centre of the case and lift out.
Page 20
Mar 13/17
To Next Page
