TECHNICAL INFORMATION
There are two nameplates located on the outside of the charger and should be used to
check this application before installation. The “Main” nameplate includes the UL Model number
and the ratings of the cabinet at its full capacity, while the “Configured Ratings” nameplate
includes the Part number and the ratings of the cabinet as configured. The Configured Ratings
nameplate label must be replaced when adding or removing modules permanently in the field.
Part Number and UL Model Number
The UL Model Number specifies the characteristics of a full cabinet charger, while the Part
Number specifies the characteristics of the cabinet as configured, plus all options. The Part
number is required in any discussion or correspondence regarding this unit.
Single Display Cabinet:
NIP3 - JN – 4YT L25
Model Type
Phase
Output Power
Cabinet Size
DC Voltage Code
AC Line Voltage Code
Charge Profile
Options
Dual Display Cabinet:
NIP3GHR - 4YOR
Model Type
Phase
Power Level Top
Power Level Bottom
Cabinet Size
DC Voltage Code
Input Voltage Code
Charge Profile
Options
