EnerSys NexSys+ NIP1 User Manual

NexSys
®
+
Owner’s Manual
AM-NXSPLUS-OM
Rev AC October 2018
4
Output Power Letter Codes
The following table describes the letter codes to be used in charger part numbers to indicate the
Output Power of the charger.
Letter
Code
Output Power
(kW)
Number
Modules
Module Power
(kW)
A
1.0
1
1.0
B
2.0
2
1.0
C
3.0
3
1.0
D
4.0
4
1.0
E
5.0
5
1.0
F
6.0
6
1.0
G
3.5/2.5*
1
3.5/2.5*
H
7.0/5.0*
2
3.5/2.5*
I
10.5/7.5*
3
3.5/2.5*
J
14.0/10.0*
4
3.5/2.5*
K
17.5
5
3.5
L
21.0
6
3.5
M
24.5
7
3.5
N
28.0
8
3.5
Cabinet Size/Gauge Letter Codes
The following table describes the letter codes to be used in charger part numbers to indicate
the number of slots and size of the DC cables.
Letter
Code
Module
Positions
Standard Cable
Gauge
Comments
L
2
1/0
Two slot, 3.5 kW cabinet
M
3
4 AWG
Three slot, 1 kW cabinet
N
4
3/0
Four slot, 3.5 kW cabinet
P
6
2/0
Six slot, 1 kW cabinet
P
6
3/0
Six slot, 3.5 kW cabinet
R
8
3/0
Eight slot, 3.5 kW cabinet
*Three Phase/Single Phase

EnerSys NexSys+ NIP1 Specifications

General

Brand	EnerSys
Model	NexSys+ NIP1
Category	Battery Charger
Language	English
