Part Number
AC Input
DC Output
Charger
Cable
AWG
Voltage
Max Amps
Phase
Min
Cord
AWG
NEMA
Plug
Cells
kW
Max
Current
(A)
NIP3-NR-5Y
400
38.4
3
6
HW**
36/40
28
320/288
3/0
NIP3GGR-5Y
400
9.6
3
14
L16-20
12/18/24
3.5
3.5
40/36
40/36
3/0
3/0
NIP3GHR-5Y
400
14.4
3
14
L16-20
12/18/24
3.5
7.0
40/36
80/72
3/0
3/0
NIP3HHR-5Y
400
19.2
3
10
L16-30
12/18/24
7.0
7.0
80/72
80/72
3/0
3/0
NIP3HIR-5Y
400
24
3
10
L16-30
12/18/24
7.0
10.5
80/72
120/108
3/0
3/0
NIP3IIR-5Y
400
28.8
3
8
CS8165C*
12/18/24
10.5
10.5
120/108
120/108
3/0
3/0
NIP3IJR-5Y
400
33.6
3
8
CS8165C*
12/18/24
10.5
14.0
120/108
160/144
3/0
3/0
NIP3JJR-5Y
400
38.4
3
6
HW**
12/18/24
14.0
14.0
160/144
160/144
3/0
3/0
NIP1-GL-2Y
480
5.8
1
14
L8-20
12
3.5
80
1/0
NIP1-GL-3Y
480
7.1
1
14
L8-20
18/24
3.5
50/50
1/0
NIP1-HL-2Y
480
11.6
1
14
L8-20
12
7
160
1/0
NIP1-HL-3Y
480
14.2
1
14
L8-20
18/24
7
100/100
1/0
NIP1-HN-2Y
480
11.6
1
14
L8-20
12
7
160
3/0
NIP1-HN-3Y
480
14.2
1
14
L8-20
18/24
7
100/100
3/0
NIP1-IN-2Y
480
17.4
1
12
L8-30
12
10.5
240
3/0
NIP1-IN-3Y
480
21.3
1
12
L8-30
18/24
10.5
150/150
3/0
NIP1-JN-2Y
480
23.2
1
12
L8-30
12
14
320
3/0
NIP1-JN-3Y
480
28.4
1
8
CS8465C*
18/24
14
200/200
3/0
NIP3-GL-4Y
480
4.8
3
14
L16-20
12, 18, 24
3.5
80/80/60
1/0
NIP3-HL-4Y
480
9.6
3
14
L16-20
12, 18, 24
7
160/160/120
1/0
NIP3-GN-4Y
480
4.8
3
14
L16-20
12, 18, 24
3.5
80/80/60
3/0
NIP3-HN-4Y
480
9.6
3
14
L16-20
12, 18, 24
7
160/160/120
3/0
NIP3-IN-4Y
480
14.4
3
14
L16-20
12, 18, 24
10.5
240/240/180
3/0
* Non NEMA plug ** Hard-Wired only
