Location
For maximum safe operation, choose a location which is free of excess moisture, dust,
combustible material and corrosive fumes. Also, avoid locations where temperatures are high
or where liquids will drip on the charger. Do not obstruct the ventilation openings. Follow charger
warning label when mounting on or over a combustible surface. The recommended charger
mounting location should provide a radial distance of at least 28 inches away from the closest
top edge of the battery.
Cabinet Mounting
The charger must be mounted on a wall, stand, shelf or floor in a vertical position. The minimum
distance between two chargers must be 12 inches.
The charger will be installed with four 5/16 inch bolts or with the bracket supplied. See the
Mounting Dimensions section at the end of this manual for proper bolt pattern. Charger should
be permanently fastened in place.
For shelf mounting, part number 159-6LA22723 is required – two per charger.
Electrical Connections
To prevent failure of the charger, make sure it is connected to the correct line voltage.
Follow your local and National Electric Code (NEC) in making these connections.
WARNING: Make sure the power to the charger is OFF and the battery is disconnected
before connecting the input power to the terminals of the charger.
* For 208/220/240V 1kW single phase, connect L1 to terminal L and L2 to terminal N.
Grounding the Charger
Connect ground wire to terminal marked with either of the two symbols below and apply same
torque value per table above:
