Enfinity 1000TL - Page 29

29
Operating state Information display Description
Checking parameters
Real-time Power Pac=xxxxW Real-time output power
Calculate Energy
Information
Etotal=xxxxkwh Total energy produced to grid
Output Voltage Vac=xxx.xV Output voltage
Output Frequency Freq.=xx.xHz Output frequency
Output Current Iac=xx.xA Output Current
PV Input Voltage Vpv= xxxV PV input voltage
PV Input Current Ipv= xxxA
PV Input Current Ipv= xxx A PV
input current
Fault information
Isolation Fault Isolation Fault
Grounding fault or surge
voltage protection failure
Leakage Detecting Ground I Fault Leakage current over rating
Grid Fault
Fault OVR AC Over voltage rating
FaultUVR ACUndervoltagerating
Fault OFR AC Over frequency rating
FaultUFR ACUnderfrequencyrating
NoUtility NoUtility NoUtility
Fan Fault Fan Fault Fan locked or circuit fault
PV Over Voltage PV Over Voltage PV voltage ≥ Max.DC voltage
Consistent Fault Consistent Fault CPUorothercircuitryfailure
Relay Failure Relay Failure
Relay failure between
grid and inverters
DCINJHigh DCINJHigh
DC component over
rating in AC output
EEPROM Failure EEPROM Failure EEPROM’s failure
SCI Failure SCI Failure
MCUinternal
communication failure
