4.7. SOCKET AND PLUG INSTALLATION INSTRUCTIONS
Once the Mode 2 power supply cable is removed, as explained in
chapter 4.6 of the Installer Manual, please act as follow.
⚫ Socket installation
A 32 A socket (female connector) installed close to easyWallbox
installation position is required, having the following requirements:
Amperage
32A
Poles
3P (2P + PE)
Nominal Voltage
230 V
Frequency
50 Hz
Reference Standard
EN 60309-2
Both wall-mounting and switchboard-mounting versions of the socket
are acceptable.
If not present, proceed with the installation of the socket in proximity
of easyWallbox. For the installation, please refer to the plug specific
instructions. Once installed, please proceed to next instruction.
⚫ Plug installation
Install a 32 A plug (male connector), providing it with adequate
cabling, with length and section adequate to connect easyWallbox
to the installed 32 A Socket.
The 32 A plug shall have the following features:
Amperage
32A
Poles
3P (2P + PE)
Nominal Voltage
230 V
Frequency
50 Hz
Reference Standard
EN 60309-2
