CCS3100
23
User Manual R0.2
Mains
147
Freq Low Alarm
Mains Feed Low-
Frequency Fail
0,0
80,0
45,0
Hz
2
Mains
148
Freq Low Warn
Mains Feed Low-
Frequency Warning
0,0
80,0
47,0
Hz
1
Mains
149
Freq High Alarm
Mains Feed High-
Frequency Fail
0,0
80,0
55,0
Hz
2
Mains
150
Freq High Warn
Mains Feed High-
Frequency Warning
0,0
80,0
53,0
Hz
1
Mains
151
Connection Type
Mains Input Wiring
Type
0
2
2
0:(1Phase) 1:(3Phase +
Notr) 2:(3Phase)
3
Mains
152
PhaseSeq Protect
Mains Feed Phase
Sequence Protection
0
1
1
0: Passive 1: Active
2
Mains
153
Mains Faults
Mains Feed Failure
Control
0
1
0
0: Passive 1: Active
2
General Set.
154
Factory Password
3
General Set.
155
Service Password
2
General Set.
156
User Password
1
General Set.
158
Maximum Startup
Maximum Start
Actions Per Hour
2
9999
10
1
General Set.
159
Start Source
Compressor Start
Signal Input Type
0
4
0
0: Panel-DI-Modbus 1: Panel
2: Digital Input 3: ModbusRTU
4: Digital Input-ModbusRTU
1
General Set.
160
Working Mode
Compressor
Operation Mode
0
1
1
0: Manual 1: Automatic
1
General Set.
161
Idle Time S/D
Idle Time Operation
S/D
0
1
0
0: Passive 1: Active
1
General Set.
162
Horn Mode
Horn Operation Mode
0
1
0
0: Continuous 1: Pulse
1
General Set.
163
PressLose Preve.
Pressure-Loss
Prevention
0
2
0
0: Passive 1: Step 2: Slope
2
General Set.
164
Parameter Save
Parameter Saving
0
2
0
0: No 1: Save 2: Use
1
General Set.
166
Language
Language Selection
0
2
0
0: Turkish 1: English
2: User Defined
1
General Set.
167
Return Factory
Factory Settings
0
2
0
0: No 1: Factory Value
2: User Defined
3
General Set.
168
ClearFaultRecord
Alarm History Reset
0
1
0
0: No 1: Yes
3
General Set.
169
Motor Time Clear
Motor Operation Time
Reset
0
1
0
0: No 1: Yes
3
General Set.
170
Menu Logout Time
Menu Timeout
Duration
1
30
3
min
1
General Set.
171
Menu Logout
Menu Log Out
0
1
0
0: No 1: Yes
2
2.2. Parameter descriptions
2.2.1 Pressure Parameters
All parameters related to pressure are under this heading.
P002: Idle Pressure (Idle Pressure):
When the line pressure reaches/exceeds the value specified with this parameter while the device is running at load,
the device switches to idle operation.
P003: Load Pressure (Onload Pressure):
In automatic operation mode, if the line pressure reaches or drops below the value specified with this parameter
while the compressor is in stop or idle mode, the device will start to run and switch to load.
P004: Discharge Pressure Alarm Level (Line Alarm Value):
When the supply pressure reaches the value specified here, the device switches to fault mode at the end of the time
entered to the "P033 Line Pressure Alarm Delay" parameter. The protection function can be cancelled by setting the
related parameter to "0".
