enphase Envoy User Manual

Envoy Installation and Operation
 2014 Enphase Energy Inc. 141-00011 Rev 05
26
Enabling a Connection to Enphase
The Enable Connection to Enphase menu item creates a secure connection to Enphase allowing Enphase
personnel to troubleshoot the system remotely.
To open a connection to Enphase:
1. Press and hold the Envoy Menu button. After two seconds the Envoy menu appears.
2. Continue holding the Menu button. When the LCD screen displays “Enable Connection to
Enphase”, release the Menu button.
The LCD screen now reads:
Once the connection is open, the LCD will return to the default display.
Disabling a Connection to Enphase
The Disable Connection to Enphase menu item closes the secure connection to Enphase.
To close a connection to Enphase:
1. Press and hold the Envoy Menu button. After two seconds the Envoy menu appears.
2. Continue holding the Menu button. When the LCD screen displays “Disable Connection to
Enphase”, release the Menu button.
The LCD screen now reads:
Once the connection is closed, the LCD will return to the default display.
Disabling Connection
Disable Connection
To Enphase
Enabling Connection
Enable Connection
To Enphase

enphase Envoy Specifications

General

Model	Envoy
Category	Gateway
Compatibility	Enphase Microinverters
Communication	Wi-Fi, Ethernet
Networking	IEEE 802.11 b/g/n
Operating Temperature	-40°C to +65°C
Enclosure Rating	IP30
Power Supply	100-240 VAC
Power Consumption	5W typical
