Envoy Installation and Operation
 2014 Enphase Energy Inc. 141-00011 Rev 05
60
Technical Data
Communications Interface
Power line
Enphase proprietary
Ethernet
10/100 auto-sensing, auto-negotiation
USB (one or two ports, depending on
Envoy model)
USB 2.0 interface, auto-sensing, auto-negotiation
Monitoring capacity
Model numbers (SKU) ENV-120-01 and ENV-120-02 can
monitor up to 600 Enphase Microinverters.
Power Requirements
AC outlet
120 VAC, 60 Hz
Power consumption
2.5 watts typical, 7 watts maximum
Mechanical Data
Dimensions (WxHxD)
8.8” x 4.4” x 1.7”
(222.5 mm x 112mm x 43.2mm)
Weight
12 oz (340g)
Ambient temperature range
-40˚C to +65˚C (-40˚ to 149˚F)
Cooling
Natural convection – no fans
Enclosure environmental rating
Indoor - NEMA 1
Features
Standard warranty term
2 years
Compliance
UL 60950-1, EN 60950-1,
CSA22.2 No. 60950-1 and IEC 60950-1,
FCC Part 15 Class B,
CAN ICES-3(B)/NMB-3(B)
Meter accuracy
Envoy metering is qualified as +/- 5% or better.
CSI Eligibility
The Envoy is included in the List of Eligible System
Performance Meters for the CSI program.
API
Production data
