Q Cable Specifications
Specification
H07BQ-F Cable
(without “-A” designation
IEC60227 Cable
(with “-A” designation)
Voltage rating
450/750V
(connector rating up to 250V)
300/500V
Voltage withstand test (kV/1min)
AC 3.0
AC 2.0
Max DC conductor resistance (20ºC) (Ω/km)
5.433
7.98
System temperature range (ambient)
-40ºC to +65ºC
-40ºC to +65ºC
Cable temperature rating
90ºC Dry / 90ºC Wet
90ºC Dry / 90ºC Wet
Cable rating
H07BQ-F
IEC57
Certification
EN 50525-2-21
IEC 60227
Flame rating
IEC 60332-1-2
IEC 60332-1-2
Cable conductor insulator rating
H07BQ-F
IEC60227, IEC57 RVV-90
Environmental protection rating
IEC 60529 IP67
IEC 60529 IP67
UV resistance
1008Hr
1008Hr
UV exposure rating
IEC60068-2-5
IEC60068-2-5
Compliance
RoHS, OIL RES I, CE, UV
Resistant
RoHS, WEEE, CE
Maximum loop size
12 cm
8 cm
