IQ8MC/IQ8AC/IQ8HC Installation and Operation Manual
12 © 2023 Enphase Energy Inc. All rights reserved. September 2023
IOM-00029-1.0
3. Parts and tools required
In addition to the microinverters, PV modules, and racking, you will need the following:
Enphase equipment
• IQ Gateway: Required to monitor production. For installation information, refer to the
IQ Gateway Installation and Operations Manual
.
• Enphase Installer App: Download the Enphase Installer App, open it, and
log in to
your Enphase account. Use it later to scan the microinverter serial
numbers and connect to the IQ Gateway to track system installation
progress. To download, go to https://enphase.com/en-gb/installers/apps
or scan the QR code at right.
• Use a Legrand Phase Coupler (LPC-01) for a multi-phase system for phase coupling if IQ Relay is not
installed in the multi-phase system.
• Tie wraps or cable clips (ET-CLIP-100 works with both single-phase and multi-phase IQ Cable)
• IQ Sealing Cap (Q-SEAL-10): for any unused connectors on the IQ Cable.
• IQ Terminator (Q-TERM-R-10 for single-phase or Q-TERM-3P-10 for multi-phase): One for each AC
cable segment end; typically, two are needed per branch circuit.
• IQ Disconnect Tool (Q-DISC-10)
• IQ Field Wireable Connectors (male and female: single-phase; Q-CONN-R-10M and Q-CONN-R-
10F; multi-phase: Q-CONN-3P-10M and Q-CONN-3P-10F)
•
IQ Cable:
Cable model
Connector
spacing
PV module
orientation
Connector count
per box
Single-phase
Q-25-10-240
1.3 m
Portrait
240
Q-25-17-240 2.0 m Landscape (60-cell) 240
Q-25-20-200
2.3 m
Landscape (72-cell)
200
Multi-phase
Q-25-10-3P-200
1.3 m
Portrait
200
Q-25-17-3P-160
2.0 m
Landscape (60-cell)
160
Q-25-20-3P-160
2.3 m
Landscape (72-cell)
160
• IQ Raw Cable (Q-25-RAW-300 for single-phase, Q-25-RAW-3P-300 for multi-phase): Length 300
meters. Raw cable with no connectors (optional).
Other items
• AC junction box
• Terminal screwdrivers
• Wire cutters, multimeter
• Torque wrench, sockets, and wrenches for mounting hardware
• Use a G99 approved third party network protection relay for PV systems with system size above 17kW
per phase.
Android
iOS

enphase IQ8AC Specifications

General

Model	IQ8AC
Manufacturer	Enphase Energy
Nominal Voltage	240 V
Frequency	60 Hz
Efficiency	97.5%
Operating Temperature Range	-40°C to +60°C
Enclosure Rating	IP67
CEC Efficiency	97%
Warranty	25 years
Output Voltage Range	211 V - 264 V
Communication	Zigbee
Weight	1.1 kg (2.4 lbs)
