enphase M250 Troubleshooting Guide

Troubleshooting an Enphase System
 2014 Enphase Energy Inc. August 2014
41
GFI Tripped
This condition occurs only with the M215, M190, D380, M210, M200, and M175 microinverters. A solid
red status LED on the microinverter indicates a ground fault (GFDI) error. The LED remains red and the
Envoy continues to report the fault until the error has cleared.
If a microinverter registers a GFI Tripped condition, you can attempt to clear this condition through the
Envoy Interface. An Envoy is required to send the clear-gfi message to clear the condition. If the
condition does not clear after you perform the following procedure, contact Enphase Energy customer
support at
support@enphaseenergy.com.
To send the clear-gfi message to a microinverter:
1. From the Administration menu, choose Device Conditions and Controls.
NOTE: Do not
check the box in the Select column.
2. Click on the serial number of the unit showing the GFI condition.
The Control Flags screen appears.
CAUTION: : Do not select the reboot and cmd-alert control flags unless recommended by
Enphase. The functions are:
 reboot - reboots the inverter
 cmd-alert - clears a condition flag for a command sent

enphase M250 Specifications

General

Model	M250
Manufacturer	Enphase Energy
Efficiency	96.5%
Output Voltage	240 V
Operating Temperature Range	-40°C to +65°C
Maximum Output Current	1.04 A
CEC Efficiency	96.0%
Start-up Voltage	22 V
Output Frequency	60 Hz
Enclosure Rating	IP67
Weight	1.6 kg
