ensto Pro EVF200 - Supply Connections

RAK112B_ENG / 2023-06-27
23 / 40
8. Supply connections
The voltage and current ratings including cables and line protector dimensioning must comply with na-
tional regulations. System dimensioning must be done by a qualied electrical designer.
EVF200
Possible supply connections:
• Use separate supply cables for each charging point
• Use one supply cable and chain internally to the charging points
L1
L3L1 L2N PE
L2 L3
N
PE
L1 L2 L3
N
PE
