EVTL36.00 concrete foundation adapter for EVF200
The concrete foundation adapter is designed to be used with a concrete foundation, product code SJR-08,
supplied by Sähkö-Jokinen Oy. Please order the foundation from: https://www.sahkojokinen./en
If you want to use a foundation from another manufacturer, make sure that the foundation is compatible with
the adapter.
EVTL35.00 mounting box for EVF300
EVTL35.00 is a ground mounting box with cable entry from bottom to the main board.
184
415
578
Ø14
Ø115
8450
66
M12
150
3
575
415
110
80
110
374
96
4x Ø14
Ø14
415
304
196
Cable glands M40x1.5
