Section 4 Discrete I/O 21
Discrete I/O
The inputs and outputs are accessible via connectors P1, P2, P3, P4 and P5. The connectors are two-
part terminals for use with wires up to 1 mm
2
If the iPAK2 is supplied fitted into a case some connections will have been pre-wired by BF ENTRON.
See the case wiring diagram for details.
